SBC81203 LGA775 SBC User's Manual
2.4.10 AXIOM ACPI Connector: CN4
It is to support remote power on/off for turning off the system through
software control while using the ATX-compliant power supply.
Pin
1 EXTSMI
3 POWER BUTTOM
5 SUSB
CN4
2.4.11 Internal Mouse/Keyboard Connector: MS1/KB1
The board provides a keyboard (KB1) and Mouse (MS1) interface with
two 5-pin connectors.
16
Signal Pin
2 GND
4 GND
6 +5VSB
6 5 4 3 2
Clock Clock Clock Clock 1 1 1 1
Data Data 2 2 2 2
Data Data
No Connection No Connection No Connection No Connection 3 3 3 3
GND GND GND GND 4 4 4 4
Power Power 5 5 5 5
Power Power
Signal
1
Jumpers and Connectors
