10/100/1000Mb
Dual PCI-Express LAN
Wake On LAN support
Serial ATA
Built-in four SATA/SATA II ports onboard support the
maximum transfer rate up to 300MB/sec
Audio
Realtek ALC203 Audio Codec onboard
Hardware Monitoring
Controller: Winbond W83627HF-AW detection of CPU
temperature, system temperature, power failure and fan
speed
Watchdog Timer
Software programmable time interval and hardware reset
only.
1~256 seconds; up to 256 levels
Dimensions: 338x 126mm (6 layer)
NOTE:
Specifications are subject to change without notice.
1.2
Utilities Supported
®
Intel
945G Utility and Drivers
VGA Drivers
Ethernet Utility and Drivers
Audio Utility and Drivers
Introduction
SBC81203 LGA775 SBC User's Manual
3
