SBC81203 LGA775 SBC User's Manual
IDE Channel 0 Master/IDE Channel 0 Slave/IDE Channel 1
Master/IDE Channel 1 Slave
These items identify the types of each IDE channel installed in the
computer. There are 45 predefined types (Type 1 to Type 45) and 2
user's definable types (Type User) for Enhanced IDE BIOS. Press
<PgUp>/<+> or <PgDn>/<−> to select a numbered hard disk type,
or directly type the number and press <Enter>. Please be noted
your drive's specifications must match the drive table. The hard
disk will not work properly if you enter improper information. If your
hard disk drive type does not match or is not listed, you can use
Type User to manually define your own drive type.
If selecting Type User, you will be asked to enter related
information in the following items. Directly key in the information
and press <Enter>. This information should be provided in the
documentation from your hard disk vendor or the system
manufacturer.
If the HDD interface controller supports ESDI, select "Type 1".
If the HDD interface controller supports SCSI, select "None".
If the HDD interface controller supports CD-ROM, select "None".
number of cylinders LANDZONE
CYLS.
number of heads
HEADS
PRECOMP write precom
If there is no hard disk drive installed, select NONE and press
<Enter>.
Dive A type/Drive B type
This item identifies floppy disk type drive A or drive B installed in the
computer.
None
No floppy drive installed
360K, 3.5 in
3.5 inch PC-type standard drive; 360Kb Mini ITXcity
3.5 inch AT-type high-density drive; 1.2MB Mini
1.2M, 3.5 in
ITXcity
3.5 inch double-sided drive; 720Kb Mini ITXcity
720K, 3.5 in
3.5 inch double-sided drive; 1.44MB Mini ITXcity
1.44M, 3.5 in
3.5 inch double-sided drive; 2.88MB Mini ITXcity
2.88M, 3.5 in
30
landing zone
number of sectors
SECTORS
MODE HDD access mode
Award BIOS Utility
