SPLITMUX Quad Screen Video Splitter

SPECIFICATIONS

Video Signal Supported
Resolution supported
HDMI supported- Inputs
HDMI supported- Output
Audio supported
Bandwidth
HDCP
Platforms supported
Ports
Protocols supported
Operating temperature
Storage temperature
Operating and storage relative
humidity
Power
Power consumption
Dimensions WxDxH (in)
SPLITMUX-HD-4RT
SPLITMUX-HD-4RT-(2)R w/o
rackmount kit
SPLITMUX-HD-4RT-(2)R w/
rackmount kit
Case material
Regulatory approvals

INDEX

baud rate, 34
cascade settings, 28
connections, 8
custom settings, 24
default IP address, 14
Device Discovery Tool, 13
downloads, 33
Ethernet, 9
firmware update-web, 31
IRT-UNV, 64
Java Runtime Environment, 13
load layout, 27, 51, 62
log in, 14
Matrix-Y-1 cable, 34
mounting, 4
HDMI and DVI
1080p, 1920x1200
24,30 and 36 bit, xvYCC, YCbCr
24 and 30 bit sRGB
4-channel non-mixing / 1-channel mixing stereo with 16,20 or 24 bit uncompressed PCM audio
165 MHz (2.0625 Gbps)
compliant
Windows 2000/XP/Vista/7/8, Windows Server 2000/2003/2008, Solaris, Linux, FreeBSD, and
MAC OS 9/10.
1- HDMI output
4- HDMI inputs
1- RJ45 Ethernet
1- RJ45 RS232
1- 2.1mm x 5.5mm power jack
HTTP, HTTPS, TCP/IP, DHCP, UDP, ARP, IPV4
32 to 122°F (0 to 50°C).
-22 to 140°F (-30 to 60°C).
17 to 90% non-condensing RH.
120VAC or 240VAC at 50 or 60Hz-5VDC/3A AC Adapter
15W
7.35x4.98x1.09 (187x126x28 mm)
7.35x4.98x1.75 (187x126x45 mm)
19x4.98x1.75 (483x126x45 mm) (excludes cable tray)
(cable management tray adds 3.37" to depth)
powder coated steel
CE, RoHS
network settings, 18
OSD menus, 53
output settings, 20
Password, 14
RS232 pinout, 34
save layout, 27, 51, 62
serial settings, 16
system information, 32
Telnet, 36
terminal, 8
text menu, 37
username and password, 14
users, 30, 43
web browsers supported, 2
69
