SPLITMUX Quad Screen Video Splitter
System Settings
Unit Settings
Name
Keypad Pin
Serial Port Settings
Baud Rate
Serial Address
OSD Screen Settings
Horiz Offset
Vert Offset
Configuration Backup and
Restore
Choose file
Upload Config
Download Configuration File
Restore Defaults
Description
Unique name for this SPLITMUX to appear on the login page and header of each web interface
page
PIN number that must be entered before using the keypad to change settings- 4 digits using
buttons 1-4.
Baud rate for RS232 commands- select a value between 1200 and 115200 bps
Serial Address for RS232 commands and for the IR Remote- select value from 1-15
OSD Horizontal Offset from left (0-70%)
OSD Horizontal Offset from top (0-70%)
Browse for a saved configuration file to be restored to the SPLITMUX. Upon selection, press
"Save" and the SPLITMUX will restore the configuration settings and reboot. Allow 1 minute
before trying to reconnect and log in again.
Note: The IP address will be set to the IP address in the file and may be different
Note: Before overwriting the existing configuration, consider whether the existing
configuration should be saved first. If it will be saved, be sure to save the current
configuration file under a different name than the configuration file to be loaded.
Click on the Browse button to browse to the file, then click on "Upload Config", and restore the
SPLITMUX to the configuration stored in the uploaded file.
Click this button to save the configuration of the SPLITMUX to a location on your PC. This file
can be restored using the "Upload Config" button in the event you wish to return the SPLITMUX
to a former state
Click this button to restore the SPLITMUX to the configuration settings it had upon receipt from
the factory. Be careful! This will erase all user configuration settings. Upon restoration, the
SPLITMUX will reboot. Allow 1 minute before trying to reconnect and log in again.
Confirmation is required.
