Save and Recall

To save a configuration of channels on the display using the IR Remote control, the <Save> and <Recall> buttons are provided.
Up to 10 configurations can be saved and recalled. Once the display has the configuration you want to be able to quickly return
to, press the <Save> button followed by two digits (01-10).
followed by the associated two digit number.

Multiple Switch Control

All NTI SPLITMUX-HD-4RT will work with the same IRT-UNV IR Remote control. As a result, a user with multiple NTI
SPLITMUXs may find that, if the switches are installed too close together, both switches may respond to an IR command intended
only for one switch. Or, the user may want to control multiple switches with a single remote, instead of having one remote per
switch. To accommodate this situation, the IRT-UNV IR Remote provides the "SYS" button, which can be used to select the NTI
switch to be controlled.
All switches will have the capability to allow the user to set the switch address (0-15) (see page 16, 40 or 54 ). Each switch to
be separately controlled must be set to a different address prior to using the Remote Control.
With the addresses set;
press the <SYS> button on the IRT-UNV,
followed by a single (i.e. <1>) or two digit number (i.e. <0> + <1>) corresponding to the address of the switch to be
controlled,
followed by <ENTER>.
Upon accepting the SYS command, the switch with the corresponding address will illuminate the "IR" LED in green for visual
indication and respond to all IR Remote commands. All other units will illuminate in red and ignore any further commands.
Note: To prepare to send a command to all at the same time, press "SYS", "0", then "ENTER".
illuminate green to indicate readiness to receive commands.

Technical Specifications For IRT-UNV

Number of Controllable Systems
Pushbutton Control
Power supply
Chassis material
Approvals

Troubleshooting the IRT-UNV

PROBLEM
IRT-UNV is not selecting inputs
or changing modes
To recall a configuration at any time, press the <Recall> button
Max: 15
29 keys
2x AAA Battery
Plastic
RoHS
SOLUTION
•
Check battery
•
The IRT-UNV may be configured to control the wrong switch- see "Multiple
Switch Control" above.
65
All LEDs will
