SPLITMUX Quad Screen Video Splitter
Administration- Input Settings
Input Settings
Input Channel x Port Name
Enable
EDID Mode
Each Input channel can be configured with these settings.
Figure 19- Input Settings
Description
Enter a port name to associate with the video source on Input 1
Choose to Enable or Disable the video input for this channel
Choose to get EDID data for channel x from:
Default 1- the default EDID table,
Copy from Output- once from the display on the output channel,
Follow Output- continuously senses the connected display and will retrieve the EDID
data on the fly from any display that gets connected to the output channel.
19
