SPLITMUX Quad Screen Video Splitter
Important server settings that determine your ability to connect the SPLITMUX and stay connected are found under Server
Settings.
Server Settings
Enable Telnet Change to "Enable" to permit access to the SPLITMUX via Telnet
The default is disabled.
Allow HTTP access Change to "Enable" to allow access to the SPLITMUX via standard (non-secure) HTTP requests
The default is disabled.
HTTP Port Port to be used for standard HTTP requests (default is 80)
HTTPS Port Port to be used for HTTPS requests (default is 443)
Web Timeout Number of minutes after which idle web users will be logged-out (maximum is 32000, enter 0 to disable
this feature)

User Configuration

The configured users are listed on the Configure User screen (Main Menu—>4). Up to 15 users can be configured to access the
SPLITMUX (16 total including "root"). Select a user and press Enter to edit the user settings, Tab to "Add User" to create a new
one, or Tab to Delete.

Figure 43- Text Menu-Server Settings

Figure 44- Text Menu- Users List

43
