SPLITMUX Quad Screen Video Splitter
The main network settings required to connect the SPLITMUX to your network are found under IP Settings.
IP Settings
Mode
IP Address
Subnet Mask
Default Gateway
Primary DNS Address
Alternate DNS Address
Note: If you select "DHCP" for the mode, make sure a DHCP server is running on the network the SPLITMUX is
connected to.
If, upon bootup, the SPLITMUX does not find a DHCP server, the SPLITMUX can be accessed using its default IP address and
network settings (above).
Note: The IP address shown here is only used when the IPv4 mode is set to "STATIC". To view the IP address when the
mode is set to "DHCP", go to the "System Information" page (page 52).

Figure 42-Text Menu- IPv4 Network Settings

(Default settings are shown in this image)
Select the method for acquiring IP Settings- Static (manual), DHCP (automatic) or Disable
Enter valid IPv4 address (for Static Mode) (default is 192.168.1.30)
Enter valid subnet mask (for Static Mode)
Enter valid default gateway (for Static Mode)
Enter preferred name server (for Static Mode)
Enter alternate name server (for Static Mode)
42
