INTRODUCTION

The SPLITMUX® HD Quad Screen Multiviewer allows you to simultaneously display video from four different computers or video
sources on a single monitor providing resolutions up to 1920 x 1200.
Features:
•
Quad, Picture in Picture, Full Screen, and Custom display modes.
•
Independent video in to video out resolution.
•
Supports HDTV resolutions to 1080p and computer resolutions to 1920x1200.
•
Connect digital sources to the splitter and display images on a digital monitor.
•
HDMI features supported:
o Inputs: 24-, 30-, and 36-bit xvYCC, sRGB, and YCbCr.
o Outputs: 24- and 30-bit sRGB.
o Four-channel non-mixing or one-channel mixing stereo with 16-, 20-, or 24-bit uncompressed PCM audio.
o Bandwidth up to 165 MHz (2.0625 Gbps).
•
Any DVI source or display can be connected by using the DVI-HD-xx-MM cable (not included).
o Use DVIA-HD-CNVTR-LC or DVI-HD-CNVTR DVI + Audio to HDMI Converters to pass and independently
switch audio signals to the multiviewer.
•
Supports digital DVI (with DVI-HD-xx-MM cables, not included) and HDMI.
•
HDCP compliant
•
On-screen display
•
Fluid, real-time video performance with 60 frames per second (fps) in all four quadrants
•
Switch audio independently of video from HDMI sources
•
Control the multiviewer through the front panel buttons, on screen display (OSD), RS232 serial port, infrared remote
control or Ethernet.
•
HDMI-embedded audio switching (four-channel stereo, non-mixing or one-channel stereo, mixing).
•
Backup and restore multiviewer configuration.
•
Select default EDID or copy EDID from output monitor.
o Supported output resolutions can be selected or set to auto detect.
•
Available options: desktop unit, 1RU rackmount unit, dual side-by-side rackmount units in 1RU.
o Rackmount units can be mounted so that the front panel buttons are facing the front or back of the rack.
Rackmount units include cable management shelf.
o
