INSYS 56k Small INT 2.0 Manual Manual page 93

INSYS Modem 56k Small INT 2.0
S91* Transmit Level
The value for the transmit level of the modem is stored in the S91 registry. The
value can be set between 0 and 15. The connection can in some cases be improved
by decreasing the transmit level.
S91=0
S91=15
Note:
S95* Result Code Control – Result code
Bit
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Transmit level 0 dBm
Transmit level -15 dBm
The range and the default value depend on the country settings
(AT+GCI).
Meaning
CONNECT message with line speed
CONNECT/ARO message for error corrected connection
CARRIER messages enabled (messages 40 – 47)
PROTOCOL messages enabled (messages 70 – 80)
Reserved
COMPRESSION message enabled (messages 66 - 69)
Reserved
Reserved
S Registry
93
