Selective Call Acceptance - INSYS 56k Small INT 2.0 Manual Manual

INSYS Modem 56k Small INT 2.0
Configuration with HSComm
Direct configuration with the HSComm is not intended. The AT command to
define a fixed baud rate can be sent to the INSYS Modem 56k Small INT 2.0 via
the entry field "Initialization string" (Page 27, Figure 5: HSComm Modem - Tab
Modem, Position 13).
Configuration with AT commands
To select the compression type, use:
To completely switch off the compression, use
the following commands:
To select the MNP4 compression:
To select the V42bis and V.44 data compres-
sion if they are switched on (see below):
To select the V42bis and MNP5 data compres-
sion if V42.bis compression is switched on (see
below):
To switch on V.42bis compression:
To switch on V.44 compression:
To switch off V.42bis compression:
To switch off V.44 compression:
12.8

Selective Call Acceptance

If the selective call acceptance is activated, the INSYS Modem 56k Small INT 2.0 will only
accept calls from previously defined callers. The INSYS Modem 56k Small INT 2.0 will
identify the caller via CLIP. This must, however, be supported by the network provider or
the phone system, where the modem is connected to. The list of phone numbers of the
INSYS Modem 56k Small INT 2.0 has 8 storage locations altogether (N0 to N7).
Configuration with HSComm
Direct configuration with the HSComm is not intended. This function can only
be configured via AT commands.
AT%C<n>
AT%C0
AT+DS44=0
AT%C1
AT%C2
AT%C3
AT%C2
AT+DS44=3
AT%C0
AT+DS44=0
Functions
35
