AT Command Reference
Command
ATX<n>
AT*X
AT&Y<n>
ATZ<n>
74
Description
Extended result messages, dial tone detection
The command determines which group of messages the INSYS Modem 56k Small INT
2.0 sends to the PC. This is important for PBXs, as a leading 0 or 9 must often be dialed
before a dialing tone is heard on the line. Blind dialing (dialing without detecting the
dialing tone) is activated or deactivated according to the parameter. The detection of
the dialing tone, however, can always be enforced using the parameter W in the ATD
dialing string (see command ATD). In the mode AT+FCLASS=1,2 the INSYS Modem
56k Small INT 2.0 always sends the message CONNECT to the PC without specifying the
transmission speed.
ATX0 No detection of the dialing tone, i.e. an unsuccessful dialing attempt
leads to the message NO CARRIER.
No detection of the busy signal, i.e. when calling a busy line the mes-
sage NO CARRIER is displayed. The message is displayed without
specifying the speed.
ATX1 As ATX0, but the CONNECT message contains the speed specification.
Dialing tone detection is active, i.e. a dialing attempt without the pres-
ATX2
ence of a dialing tone leads to the message NO DIALTONE.
No detection of the busy signal, i.e. when calling a busy line the mes-
sage NO CARRIER is displayed.
ATX3 No detection of the dialing tone, i.e. an unsuccessful dialing attempt
leads to the message NO CARRIER.
Busy signal detection active, i.e. when calling a busy line the message
BUSY is displayed.
ATX4 Dialing tone detection is active, i.e. a dialing attempt without the pres-
ence of a dialing tone leads to the message NO DIALTONE. (default)
Busy signal detection is active, i.e. when calling a busy line the message
BUSY is displayed.
Terminate remote configuration
The command AT*X terminates a remote configuration.
Selection of user configuration for hardware reset
AT&Y0 For a hardware reset following the AT&Y0-command, the user default 0
(created using the AT&W0 command) is loaded into the current modem
configuration.
AT&Y1 For a hardware reset following the AT&Y1-command, the user default 1
(created using the AT&W1 command) is loaded into the current modem
configuration.
Software reset
The command causes the INSYS Modem 56k Small INT 2.0 to perform a software reset.
The INSYS Modem 56k Small INT 2.0 will load the default saved by the user (according
to the parameter). If no parameter is specified, the user default 0 is loaded.
ATZ0 Software reset; afterwards the user default 0 is loaded.
Software reset; afterwards the user default 1 is loaded.
ATZ1
