Initial Operation
10
Initial Operation
This chapter describes how to activate the INSYS Modem 56k Small INT 2.0, i.e. how
to connect the INSYS Modem 56k Small INT 2.0 to a PC, to a telephone network and
how to test it.
Connect the INSYS Modem 56k Small INT 2.0to a PC
How to connect the INSYS Modem 56k Small INT 2.0 to a PC via a serial in-
terface.
You will need the 9-pin serial cable.
You will need a free serial interface at the PC.
Use preferably serial interfaces which are actually at the PC as "real" hard-
ware. Virtual serial interfaces or USB-to-Serial solutions often cause prob-
lems.
1.
Connect the 9-pin serial cable with the INSYS Modem 56k Small INT 2.0 and
fasten the connection screws.
2.
Connect the 9-pin serial cable to a free serial interface of your PC.
Note or remember to which interface (COM1 or COM2) you connected the
INSYS Modem 56k Small INT 2.0 at the PC.
Connect the INSYS Modem 56k Small INT 2.0 to the telephone network
You will need the supplied phone cord
1.
Plug the RJ12 jack of the cable into the RJ45 phone connection at the INSYS
Modem 56k Small INT 2.0.
2.
Plug the TAE or RJ12 jack of the cable into the phone jack of your phone
connection.
Test the INSYS Modem 56k Small INT 2.0
The INSYS Modem 56k Small INT 2.0 is connected to the PC.
The power supply of the INSYS Modem 56k Small INT 2.0 is switched on.
A terminal program such as TeraTerm is installed at the PC.
1.
Open your terminal program.
2.
Open the serial interface, to which the INSYS Modem 56k Small INT 2.0 is
connected.
3.
Enter AT into your terminal program.
22
INSYS Modem 56k Small INT 2.0
