  • Page 1 INSYS Modem 56k Small INT 2.0 Nov-07...
  • Page 3 MNP is a registered trademark of Microcom Inc. IBM PC, AT, XT are registered trademarks of International Business Machine Corporation. INSYS ® is a registered trademark of INSYS MICROELECTRONICS GmbH. Windows™ is a registered trademark of Microsoft Corporation. Publisher:...

  • Page 4: Table Of Contents

    12.9 Sending messages via data connection, SMS or Fax ............37 12.10 Manual Sending of Messages...................39 12.11 Switching on the Remote Configuration .................39 12.12 Remote Configuration of the INSYS Modem 56k Small INT 2.0........40 12.13 Access Control and Security Callback................41 Nov-07...
  • Page 5 Contents 12.14 Idle Connection Control with Data Transmit Control............43 12.15 Priority Circuit for a Phone Connected in Series to the INSYS Modem 56k Small INT 2.0..........................44 12.16 Reset ...........................46 Maintenance ..................... 48 Waste Disposal....................50 14.1 Repurchasing of legacy systems..................50 AT Command Reference ...................

  • Page 6: Safety

    Risk of death through shock hazard when touching it! The INSYS Modem 56k Small INT 2.0 may not be used in wet or damp environments, or in or very close to water. Install the device at a dry location, protected from water spray.
  • Page 7 INSYS Modem 56k Small INT 2.0 Safety Note Damage due to chemicals! Ketones and chlorinated hydrocarbons dissolve the plas- tic housing and damage the surface of the device. Never let the device come into contact with ketones (e.g. acetone) or chlorinated hydrocarbons, such as dichloro-...

  • Page 8: Scope Of Delivery

    INSYS Modem 56k Small INT 2.0 Scope of Delivery The scope of delivery for the INSYS Modem 56k Small INT 2.0 includes all accessories listed below. Please check if all accessories are included in the box. If a part is missing or damaged, please contact your distributor.

  • Page 9: Usage According To The Regulations

    Usage According to the Regulations Usage According to the Regulations The INSYS Modem 56k Small INT 2.0 may only be used for the purposes specified in the function overview. In addition, it may be used for the following purposes: • Usage and mounting in an industrial cabinet.

  • Page 10: Technical Data

    Technical Data INSYS Modem 56k Small INT 2.0 Technical Data Physical Features Danger! Overvoltage. Fire hazard! The modem must be secured with a suitable fuse against overvoltage. All specified data was measured with a nominal input voltage, at full load, and an ambi- ent temperature of 25 °C.

  • Page 11: Display And Control Elements

    INSYS Modem 56k Small INT 2.0 Display and Control Elements Display and Control Elements Figure 1: LEDs on the front panel Position Description Power/RX/TX LED OH/DCD-LED (Off Hook / Data Carrier Detect) Table 1: Description of the LEDs on the front panel of the device...

  • Page 12: Connections

    Connections INSYS Modem 56k Small INT 2.0 Connections Front Panel Connections Figure 2: Connections on the front panel of the device Position Description Serial Interface (RS232 jack) Phone connection (RJ12 line jack) Table 1: Description of the connections on the front panel of the device...

  • Page 13: Pin Assignment Of The Serial Interface

    INSYS Modem 56k Small INT 2.0 Connections Pin Assignment of the Serial Interface Figure 3: 9-pin sub-D jack at the device Signal Description Data Carrier Detect Receive Data Transmit Data Data Terminal Ready Ground Data set ready Request to send...

  • Page 14: Rj12 Phone Connection

    Connections INSYS Modem 56k Small INT 2.0 RJ12 Phone connection b2 b1 a2 a1 Figure 4: RJ12 jack connected to TAE jack Signal Description Not connected (GND) To connect a phone in series. Incoming phone line (e.g. PSTN or PBX) Incoming phone line (e.g.

  • Page 15: Function Overview

    INSYS Modem 56k Small INT 2.0 exceed a certain level. An applica- tion can also prompt the INSYS Modem 56k Small INT 2.0 via a control line to interrupt the data flow. As an alternative, the INSYS Modem 56k Small INT 2.0 can control the data flow via XOFF/XON characters in the data...
  • Page 16 • Storing the settings in the user profiles The INSYS Modem 56k Small INT 2.0 can store the user settings in two dif- ferent "profiles". This means that two different configurations can be stored for special purposes and loaded as needed.

  • Page 17: Meaning Of The Symbols And The Formatting In This Manual

    Meaning of the Symbols and the Formatting in this INSYS Modem 56k Small INT 2.0 Manual Meaning of the Symbols and the Formatting in this Manual This section describes the definition, formatting and symbols used in this manual. The various symbols are meant to help you read and find the information relevant to you.

  • Page 18: Mounting

    Mounting INSYS Modem 56k Small INT 2.0 Mounting This chapter describes how to mount the INSYS Modem 56k Small INT 2.0 to a DIN rail, connect it to the power supply and disassemble it again. Danger! Exposed electrical components! Risk of death through electric shock hazard! Prior to the installation, switch the power of the cabinet off and secure it against being switched on again.
  • Page 19 INSYS Modem 56k Small INT 2.0 Mounting Lift the INSYS Modem 56k Small INT 2.0 perpendicular to the DIN rail until the plastic spring of the third, flexible snap-in hook engages in the DIN rail. The INSYS Modem 56k Small INT 2.0 is now completely mounted.
  • Page 20 INSYS Modem 56k Small INT 2.0 Disassemble the device from the DIN rail Instructions on how to disassemble the INSYS Modem 56k Small INT 2.0 from a DIN rail in a cabinet: You will need a Philips screwdriver with a 4.5 mm blade.
  • Page 21 While you hold the plastic spring of the snap-in hook stretched apart, pull the INSYS Modem 56k Small INT 2.0 away from the DIN rail. De-hook the INSYS Modem 56k Small INT 2.0 and take it off, perpendicularly to the DIN rail.

  • Page 22: Initial Operation

    Initial Operation This chapter describes how to activate the INSYS Modem 56k Small INT 2.0, i.e. how to connect the INSYS Modem 56k Small INT 2.0 to a PC, to a telephone network and how to test it. Connect the INSYS Modem 56k Small INT 2.0to a PC How to connect the INSYS Modem 56k Small INT 2.0 to a PC via a serial in-...
  • Page 23 The RX/TX LED light up while you type. If the RX/TX LED at the INSYS Modem 56k Small INT 2.0 does not light up, while you type AT and receive an OK, the reason may be that you are con- nected to another modem (e.g.

  • Page 24: Operating Principle

    You have two possibilities to operate and configure the INSYS Modem 56k Small INT 2.0. In general, the INSYS Modem 56k Small INT 2.0 is configured and operated via AT com- mands. You can enter these commands yourself with the help of a terminal program and the AT command reference.

  • Page 25: Operation With Hscomm Modem

    INSYS Modem 56k Small INT 2.0 Operating Principle Configure the INSYS Modem 56k Small INT 2.0 with the help of the AT com- mands. A reference of the AT commands can be found in the chapter "AT Com- mand Reference".

  • Page 26: User Interface Of The Software Hscomm Modem

    Click OK in the status message. A dialog box with the message "Modem settings are sent" is displayed. The entered settings are sent to the INSYS Modem 56k Small INT 2.0 and stored. A dialog box with the message "Modem settings sent" is displayed.
  • Page 27 Button to read the settings from the INSYS Modem 56k Small INT 2.0. Button to reset the INSYS Modem 56k Small INT 2.0. Button to send the default settings to the INSYS Modem 56k Small INT 2.0. Display/function not available for INSYS Modem 56k Small INT 2.0.
  • Page 28 Activation of additional message dispatch for all messages. Selection of the service center for the message dispatch. Behavior of the INSYS Modem 56k Small INT 2.0 for events at the inputs. Tab to select the different configuration areas. Table 7: Description of the functions on the HSComm tab "Alarm functions"...

  • Page 29: Functions

    Modem 56k Small INT 2.0 before you change the country specific preset. The INSYS Modem 56k Small INT 2.0 holds a range of presets, which allow you to adjust the device to the standards and requirements of the local telephone network. The firm- ware of the INSYS Modem 56k Small INT 2.0 contains the presets for the so called „stan-...

  • Page 30: Automatic Baud Rate Detection

    (according to the character string "AT"), the parameters for the interface of the INSYS Modem 56k Small INT 2.0 will be checked and adjusted, if necessary. This is the reason why the baud rate can not be stored with the command AT&W, as the INSYS Mo- dem 56k Small INT 2.0 will immediately adjust its interface to the current parameters of...

  • Page 31: Phone Connection

    When the buffer is activated, the data flow control should be active to avoid a buffer overflow in the INSYS Modem 56k Small INT 2.0. If the buffer flows over, the IN- SYS Modem 56k Small INT 2.0 will perform a reset. Operation without a buffer and error correction is only useful for special character framings.

  • Page 32: Bit Direct Mode

    When the buffer is emptied sufficiently for the INSYS Mo- dem 56k Small INT 2.0 to be able to receive data again, the CTS line is set to "high". Re- versely, the application can also indicate to the INSYS Modem 56k Small INT 2.0 to inter- rupt the data flow.

  • Page 33: Software Data Flow Control (Xon/Xoff)

    INSYS Modem 56k Small INT 2.0 Functions The data flow control with RTS/CTS behavior is active by default. Configuration with HSComm Select the type of data flow control or switch it off completely on the tab Mo- dem in the panel "Handshake" (Page 27, Figure 5: HSComm Modem - Tab Mo- dem, Position 26).

  • Page 34: Error Correction

    12.6 Error correction The INSYS Modem 56k Small INT 2.0 masters the V.42 error correction protocol including the Microcom Networking Protocol Levels 2/3/4 (MNP2, MNP3, MNP4) and the data throughput optimization MNP10. The V.42 error correction includes the protocols LAPM (Link Access Procedure for Modem) and MNP4.

  • Page 35: Selective Call Acceptance

    Direct configuration with the HSComm is not intended. The AT command to define a fixed baud rate can be sent to the INSYS Modem 56k Small INT 2.0 via the entry field "Initialization string" (Page 27, Figure 5: HSComm Modem - Tab Modem, Position 13).
  • Page 36 To store the phone number <nr> in the stor- age location <n> , use: The INSYS Modem 56k Small INT 2.0 checks the phone number sent via CLIP for one of the stored numbers. The check starts on the "right", i.e. from the end of the phone number submitted by CLIP.

  • Page 37: Sending Messages Via Data Connection, Sms Or Fax

    Sending messages via data connection, SMS or Fax The INSYS Modem 56k Small INT 2.0 can send a message via SMS, data connection, or as e-mail. The sending of messages can only be triggered via an AT command. By default, three attempts are made to send a message.
  • Page 38 Please make sure to set the correct transmission type for the message of the INSYS Modem 56k Small INT 2.0. If you set SMS to mobile phone via D2, for example, you can only send SMS to mobile phones in the D2 network.

  • Page 39: Manual Sending Of Messages

    12.11 Switching on the Remote Configuration The INSYS Modem 56k Small INT 2.0 can be configured remotely. It has a remote configu- ration mode. To configure the INSYS Modem 56k Small INT 2.0 remotely, a data connec- tion to the modem to be configured must be established. This can be performed by call- ing the INSYS Modem 56k Small INT 2.0 from any modem.

  • Page 40: Remote Configuration Of The Insys Modem 56K Small Int 2.0

    You will need a terminal program. Open your terminal program. Establish a connection to the INSYS Modem 56k Small INT 2.0. Use the local modem to dial the phone number of the INSYS Modem 56k Small INT 2.0 with ATD<phonenumber>.

  • Page 41: Access Control And Security Callback

    AT commands are ATA, ATD, ATO, AT&F, AT/B. Complete the remote configuration by entering AT*E. The INSYS Modem 56k Small INT 2.0 is now in the normal data connection mode. You can now exchange data between your local modem and the IN- SYS Modem 56k Small INT 2.0, or terminate the connection.
  • Page 42 Please note: If you operate the INSYS Modem 56k Small INT 2.0 at a phone sys- tem, which will not provide an exchange after going off-hook, enter the char- acter for the exchange together with the phone number.

  • Page 43: Idle Connection Control With Data Transmit Control

    Modem 56k Small INT 2.0 to stay online for an unlimited amount of time, although no data is being transmitted anymore. The DTC function can define the time after which the INSYS Modem 56k Small INT 2.0 will hang up as soon as there is no data transfer on the phone line.

  • Page 44: Priority Circuit For A Phone Connected In Series To The Insys Modem 56K Small Int

    TheINSYS Modem 56k Small INT 2.0 can determine on the basis of the voltage in the line, if the phone line is used by a phone, if a phone in series is going off- hook or if the remote terminal of the INSYS Modem 56k Small INT 2.0 is terminating the connection.
  • Page 45 (the crackling noise in the line) that the remote terminal has hung up. This will set the event code of the S registry 86 to 25 (remote terminal has hung up). This means that the INSYS Modem 56k Small INT 2.0 will not keep the line busy for an unneces- sarily long period.

  • Page 46: Reset

    12.16 Reset There are several methods to reset the INSYS Modem 56k Small INT 2.0 : by cutting off the supply voltage, by pushing the reset button on the front of the device, by connecting the terminal „RESET“ with the terminal „GND“, by using the software HSComm and by using an AT command.
  • Page 47 To reset the INSYS Modem 56k Small INT 2.0 ATZ1 and load the settings stored in user profile „1“, use the command To reset the INSYS Modem 56k Small INT 2.0 to AT&F&WZ factory defaults, use the command...

  • Page 48: Maintenance

    INSYS Modem 56k Small INT 2.0. The firmware of the INSYS Modem 56k Small INT 2.0 can be updated to add more func- tions to the INSYS Modem 56k Small INT 2.0 or to improve the existing functions. A firmware update can be performed with the help of a terminal program that supports ASCII uploads (e.g.
  • Page 49 The input buffer at the serial interface of the INSYS Modem 56k Small INT 2.0 flows over and the INSYS Modem 56k Small INT 2.0 resets itself. In this case, you will hear the relays click during the uploads. It is possible that an error message is displayed.

  • Page 50: Waste Disposal

    Waste Disposal INSYS Modem 56k Small INT 2.0 Waste Disposal 14.1 Repurchasing of legacy systems According to the new WEEE guidelines, the repurchasing and recycling of legacy systems for our clients is regulated as follows: Please send those legacy systems to the following address, carriage prepaid: Frankenberg-Metalle Gärtnersleite 8...

  • Page 51: At Command Reference

    Start of the flash load function Answer mode The INSYS Modem 56k Small INT 2.0 modem is switched into response mode. This is only effective in Germany, if the connected phone goes off-hook or if a call comes in. Repeat the last command The last command is repeated.
  • Page 52 For connections that were not error corrected the INSYS Modem 56k Small INT 2.0 sends a break signal to the other INSYS Modem 56k Small INT 2.0. The length of the signal is: the specified parameter times 1/10 of a second.
  • Page 53 Setting AT+CMGF=1 (text mode): AT+CMGS=<phonenumber> The INSYS Modem 56k Small INT 2.0 returns the “>” character and awaits the SMS text (up to 160 characters), ending with an EOF character (0x1A or STRG-Z). Notes: Depending on the provider, the phone number must be entered in the format "0941xxxx"...
  • Page 54 AT Command Reference INSYS Modem 56k Small INT 2.0 Command Description erence defined in the PDU string. AT+CPIN? Dummy command for GSM compatibility AT+CPIN? responds with "+CPIN: READY". Note: This command only serves for the purpose of compatibility with applications for GSM devices.
  • Page 55 NO CARRIER. In the mode FCLASS=1 or =2, the INSYS Modem 56k Small INT 2.0 acts as a fax modem. It attempts to connect to another fax or fax modem. (The INSYS Modem 56k Small INT 2.0 goes into receive status HDLC V.21 channel 2, as if the command AT+FRH had been...
  • Page 56 Dialing the n-th number from the number pool, which was set up with the AT&Z<n> command. If the character ”!” is a part of the dialing string, the INSYS Modem 56k Small INT 2.0 will hang up within the time frame determined in S29 and then goes off-hook again.
  • Page 57 AT&F Loading the default factory settings The INSYS Modem 56k Small INT 2.0 loads the default factory setting from the internal, nonvolatile memory. This puts the INSYS Modem 56k Small INT 2.0 into a defined basic state. AT&F also overwrites a part of the S registry.
  • Page 58 Connection setup takes place with 1,200 bps AT*H1 AT*H2 Connection setup takes place with 4800 bps ATI<n> Identification The INSYS Modem 56k Small INT 2.0 sends an identification to the PC, according to the following parameter: Product code ATI0 ATI1 Previously calculated EPROM checksum...
  • Page 59 INSYS Modem 56k Small INT 2.0 AT Command Reference Command Description AT&K<n> Select data flow control between the PC and the INSYS Modem 56k Small INT 2.0 (hand- shake) Fax operation default is RTS/CTS. No data flow control AT&K0 AT&K3 Select data flow control RTS/CTS (default) AT&K4...
  • Page 60 Break control AT\K The INSYS Modem 56k Small INT 2.0 reacts to a break (receive path OFF for a certain amount of time), which it receives from another modem or from the PC, or from the command AT\B according to the parameters.
  • Page 61 AT%L Display level of the received signal The value that is reported from the INSYS Modem 56k Small INT 2.0 equals the already amplified level within the INSYS Modem 56k Small INT 2.0, not the phone line level. Large AT%L responses imply a low signal level; small values imply a high signal level (009 = -9db, 043 = -43db) AT*L<n>...
  • Page 62 Switches the display function ON. The displayed value applies to the received data. If the display function is switched on the INSYS Modem 56k Small INT 2.0will display the modulation type and the line speed after the message CONNECT. After the message CONNECT, the line „+MCR:”...
  • Page 63 Automatic modulation adjustment switched off Automatic modulation adjustment switched on Parameter Reception Minbaud: The optional parameter minbaud determines the lowest possible baud rate for INSYS Modem 56k Small INT 2.0 reception. Parameter Reception Maxbaud: The optional parameter maxbaud determines the highest possible baud rate for INSYS Modem 56k Small INT 2.0 reception.
  • Page 64 AT Command Reference INSYS Modem 56k Small INT 2.0 Command Description AT*M<n> Remote terminal selection Defines the protocol that is used to send the alarm string to the network provider. The remote terminal is a normal fixed network modem (default)
  • Page 65 INSYS Modem 56k Small INT 2.0 report RING for an incoming call or will accept the call according to the settings of ATS0 (the line RI is activated with each call, irre- spective of that fact).
  • Page 66 Switches the password query on after the connection has been estab- lished. If the password query is activated, the INSYS Modem 56k Small INT 2.0 will query the password after CONNECT has taken place. After the password has been entered cor- rectly, the actual CONNECT will take place and data may be transmitted.
  • Page 67 (AT&N<n>), calls from a previously defined phone num- ber can take place without a ring of the phone connected in series. If the phone number is not detected by the INSYS Modem 56k Small INT 2.0, the phone is switched on again after the first ring.
  • Page 68 The DSR signal is on the DCD line The DCD signal is on the DSR line (Interchangeability of the lines) AT&S DSR behavior This command determines how the INSYS Modem 56k Small INT 2.0 treats its DSR (CT107) output. AT&S0 DSR always ON (default). AT&S1 DSR ON after a response tone has been detected;...
  • Page 69 Priority circuit for INSYS Modem 56k Small INT 2.0 with phone connected in series The INSYS Modem 56k Small INT 2.0 gives a phone connected in series priority, to make sure it interferes as little as possible with the usage of the phone connection.
  • Page 70 2 stop bits ATV<n> Format of modem messages This command determines if the INSYS Modem 56k Small INT 2.0 transmits messages to the application in short or long format. Messages in short format, i.e. only the error number ATV0 ATV1 Messages in long format, i.e.
  • Page 71 Definition of the common part of the alarm message (maximum of 160 characters – within HSComm limited to 120 characters) To the input AT*V the INSYS Modem 56k Small INT 2.0 responds with NEW TEXT: and expects the input of the alarm text (completed with <CR>) This command is not available in the remote operation mode.
  • Page 72 AT Command Reference INSYS Modem 56k Small INT 2.0 Command Description AT&V<n> Show the configurations AT&V0 The active configuration of the modem, the saved user defaults and the saved phone numbers 0 to 3 (the parameter 0 may be omitted) are dis- played.
  • Page 73 Error correction messages This command determines which data transmission rate information is provided for a CONNECT message. The INSYS Modem 56k Small INT 2.0 reports the baud rate between ATW0 INSYS Modem 56k Small INT 2.0 and application. (default) ATW1 During the connection setup, the INSYS Modem 56k Small INT 2.0 re-...
  • Page 74 The command causes the INSYS Modem 56k Small INT 2.0 to perform a software reset. The INSYS Modem 56k Small INT 2.0 will load the default saved by the user (according to the parameter). If no parameter is specified, the user default 0 is loaded.
  • Page 75 INSYS Modem 56k Small INT 2.0 AT Command Reference Command Description AT&Z<n> Save phone numbers The command saves four entries permanently in the EEPROM. Each entry may consist of up to 35 characters. The entries may be overwritten and must comply with the dial- ing string as described in the ATD command.

  • Page 76: At Messages

    AT Command Reference INSYS Modem 56k Small INT 2.0 15.1 AT Messages List of message numbers and messages texts depending on the command ATX. Message Num- Message text in long form ATX<0> ATX<1> ATX<2> ATX<3> ATX<4> Short form +FCERROR CONNECT...
  • Page 77 INSYS Modem 56k Small INT 2.0 AT Command Reference Message Num- Message text in long form ATX<0> ATX<1> ATX<2> ATX<3> ATX<4> Short form CARRIER 16800 CARRIER 19200 CARRIER 21600 CARRIER 24000 CARRIER 26400 CARRIER 28800 CONNECT 16800 CONNECT 21600 CONNECT 24000...
  • Page 78 AT Command Reference INSYS Modem 56k Small INT 2.0 Message Num- Message text in long form ATX<0> ATX<1> ATX<2> ATX<3> ATX<4> Short form CONNECT 46000 CONNECT 48000 CONNECT 50000 CONNECT 52000 CONNECT 54000 CONNECT 56000 CONNECT 230400 CARRIER 28000 CARRIER 29333...

  • Page 79: Country Codes

    INSYS Modem 56k Small INT 2.0 Country Codes Country Codes Adjust the modem to local requirements using the command AT+CGI=<countrycode> All other settings should be carried out after the country code has been selected, because some factory settings depend on the country.
  • Page 80 Country Codes INSYS Modem 56k Small INT 2.0 INSYS modem 336/56k 4.1 (UL) Country Standard coun- Extended tries Country group Finland* FD/3C France* FD/3D Gabun Ghana Greece* FD/46 Greenland Great Britain* FD/B4 Guatemala Honduras Hong Kong India Indonesia Ireland* FD/57...
  • Page 81 INSYS Modem 56k Small INT 2.0 Country Codes INSYS modem 336/56k 4.1 (UL) Country Standard coun- Extended tries Country group Liechtenstein* Lithuania Luxembourg* FD/69 Madagascar Malawi Malaysia Malta Mauritania Mauritius Macedonia Mexico Monaco Moldawia Montenegro New Zealand Nicaragua Netherlands* FD/7B...
  • Page 82 Country Codes INSYS Modem 56k Small INT 2.0 INSYS modem 336/56k 4.1 (UL) Country Standard coun- Extended tries Country group Saudi Arabia Sweden* FD/A5 Switzerland FD/A6* Senegal Serbia Singapore Zimbabwe Slovak Republic Slovenia Spain* FD/A0 Sri Lanka South Africa Taiwan...

  • Page 83: S Registry

    INSYS Modem 56k Small INT 2.0 S Registry S Registry S registries may be read and written using the ATS<n> command. (see also AT Command Reference). Certain S registries may only be read; into others only a particular range of values may be entered.
  • Page 84 S Registry INSYS Modem 56k Small INT 2.0 Tabs Function Units Range Default Time period for modifier “flash” 10 ms 0-17 Time period until hang up due to silence 10 s 0-255 S31* General settings S36* Reset of error logs...

  • Page 85: Description S Registry

    INSYS Modem 56k Small INT 2.0 S Registry 17.2 Description S Registry Note: Registries marked with *) are stored in the user defaults with the command AT&W- Befehl. Number of ringing tones until automatically going off-hook Number of rings until the modem goes off-hook For S0=0 the modem will not go off-hook when a call comes in.
  • Page 86 S Registry INSYS Modem 56k Small INT 2.0 Dial tone delay Dial pause time, if a comma is included in the dialing string. If there is a comma in the dialing string, the modem will wait during the dialing procedure, until the time specified in S8 (in seconds) has run out.
  • Page 87 INSYS Modem 56k Small INT 2.0 S Registry Bit 6 Reserved Bit 7 Originate/answer Originate/answer 0: Answer mode 1: Originate mode S15* DTC Time Settings The idle connection control is a function integrated in the firmware which moni- tors the data transmission in online mode. This function prevents the modem to stay online for an unlimited amount of time, although no data is being transmit- ted anymore.
  • Page 88 S Registry INSYS Modem 56k Small INT 2.0 S22* Speaker system settings Meaning Bit 0.1 Speaker volume Speaker volume: 0: Off (ATL0) 1: Silent (ATL1) 2: Medium (ATL2) 3: Loud (ATL3) Bit 2-3 Speaker control Speaker control: 0: Off (ATM0)
  • Page 89 INSYS Modem 56k Small INT 2.0 S Registry S27* General settings Meaning Bit 0-3 RS232-Mode Asynchronous Mode Selection: 0: see AT&M0 or AT&Q0 9: see AT&Q5 10: see AT&Q6 Bit 4.5 Reserved Bit 6 CCITT or Bell CCITT/Bell Select Modulation...
  • Page 90 S Registry INSYS Modem 56k Small INT 2.0 S36* Reset of error logs Meaning Bit 0..2 determines what happens Modem hangs up if an attempt to establish a Modem stays online and establishes a direct V.42 LAP-M connection mode connection.
  • Page 91 INSYS Modem 56k Small INT 2.0 S Registry S40* Break handling and MNP5 block size Meaning Bit 0 Reserved Bit 1 Reserved Bit 2 Reserved Bit 3-5 Break handling Break handling 0: see AT\K0 1: see AT\K1 2: see AT\K2...
  • Page 92 S Registry INSYS Modem 56k Small INT 2.0 Error event code When a connection fails (NO CARRIER), an event code is written into this registry. S86=0 Normal disconnect, no error S86=4 Carrier lost S86=5 No establishing of an error-corrected (V.42) connection...
  • Page 93 INSYS Modem 56k Small INT 2.0 S Registry S91* Transmit Level The value for the transmit level of the modem is stored in the S91 registry. The value can be set between 0 and 15. The connection can in some cases be improved by decreasing the transmit level.

  • Page 94: Sms Provider / Service Center

    SMS Provider / Service Center: INSYS Modem 56k Small INT 2.0 SMS Provider / Service Center: Overview of network providers for German speaking countries (D, A, CH). All nec- essary information is available from the customer service center of the provider.

  • Page 95: Tables And Diagrams

    INSYS Modem 56k Small INT 2.0 Tables and Diagrams Tables and Diagrams 19.1 List of Tables Tabelle 1: Technological Features.......................10 Table 2: Meaning of the LED displays ....................11 Table 3: Description of the connections on the top of the device..........12 Table 4: Description of the pin allocation of the sub-D jack ............13...
