Mounting

9 Mounting
This chapter describes how to mount the INSYS Modem 56k Small INT 2.0 to a DIN
rail, connect it to the power supply and disassemble it again.
Mount the device to the DIN rail
Instructions on how to mount the INSYS Modem 56k Small INT 2.0 to a DIN
rail.
1. Position the device at the DIN rail as seen in the following diagram. There
are two snap-in hooks at the outer edge of the DIN rail groove of the INSYS
Modem 56k Small INT 2.0. Hook them into place behind the upper edge of
the DIN rail when connecting the device.
18
Exposed electrical components!
Risk of death through electric shock hazard!
Prior to the installation, switch the power of the cabinet
off and secure it against being switched on again.
Moisture und liquids from the environment may seep
into the interior of the INSYS Modem 56k Small INT 2.0.
Risk of death through shock hazard when touched!
The INSYS Modem 56k Small INT 2.0 may not be used in
wet or damp environments, or in or very close to water.
Install the device at a dry location, protected from water
spray. Switch the power supply off before you do any
work on a device which may have been in contact with
moisture.
The device could be destructed if the wrong power sup-
ply is used.
If the INSYS Modem 56k Small INT 2.0 is used with a po-
wer supply which has a larger voltage than the allowed
operational voltage of the INSYS Modem 56k Small INT
2.0, the device is destroyed.
Make sure that you use the suitable power supply. The
Chapter "Technical Data" has the information about the
correct voltage range for the INSYS Modem 56k Small
INT 2.0.
INSYS Modem 56k Small INT 2.0
Danger!
Danger!
Note
