S Registry
S8*
Dial tone delay
Dial pause time, if a comma is included in the dialing string. If there is a comma in
the dialing string, the modem will wait during the dialing procedure, until the
time specified in S8 (in seconds) has run out. The value of S8 can be between 1
and 7 seconds.
S9* Reaction time carrier signal
DCD response time for the carrier frequency from the other modem. The DCD
output of the RS232 interface (CT109) of the modem switches to ON, when the
carrier frequency from the other modem is detected before the time defined in S9
(in tenth of seconds) runs out. S9 must be smaller than S10.
S10* Time period between lost carrier signal and hang up
The time which leads to termination after carrier frequency loss. In S10, the time
period for which the modem waits for the disconnection if it can no longer detect
the carrier frequency from the other modem, is specified in tenth of seconds.
S12* Transmission clock of the ESC characters
Minimum pre and post run time and maximum interim time in 1/50 of seconds
between two characters. This must be observed, if the modem is supposed to de-
tect an abort sequence (usually +++).
S13* Number of dialing attempts to send a message
Bit
Bit 0 – 3
Bit 4 - 7
S14* General settings
Bit
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
86
Meaning
Number of dialing attempts
Reserved
Meaning
Reserved
Echo on inputs
Reserved
Result format
Reserved
Tone/pulse dialing
Range of values: 1...12
Default value: 3
S13 determines the number of attempts to send the
message.
Note: The limitation to a maximum of 12 at-
tempts is necessary for approval pur-
poses (black listing).
Command echo
Result codes:
Tone/pulse
INSYS Modem 56k Small INT 2.0
0: Echo off
1: Echo on
0: Message numbers (ATV0)
1: Message texts (ATV1)
0: Tone dialing (ATT)
1: Pulse dialing (ATP)
