Mounting
Disassemble the device from the DIN rail
Instructions on how to disassemble the INSYS Modem 56k Small INT 2.0
from a DIN rail in a cabinet:
You will need a Philips screwdriver with a 4.5 mm blade.
The power supply of the cabinet is switched off and secured against being
switched off accidentally.
All cables at the INSYS Modem 56k Small INT 2.0 are disconnected.
1.
Insert the Philips screwdriver into the flexible snap-in hook of the INSYS Mo-
dem 56k Small INT 2.0 as shown in the diagram.
2.
Turn the Philips screwdriver into the direction of the INSYS Modem 56k Small
INT 2.0 as shown in the diagram.
20
INSYS Modem 56k Small INT 2.0
