INSYS Modem 56k Small INT 2.0
4. Configure the INSYS Modem 56k Small INT 2.0 with the help of the AT com-
mands.
A reference of the AT commands can be found in the chapter "AT Com-
mand Reference".
5. Save your entries with AT&W.
Not all settings at the INSYS Modem 56k Small INT 2.0 must be actively
stored by entering AT&W. Some settings are automatically saved immedi-
ately. We still recommend sending the command AT&W to the INSYS Mo-
dem 56k Small INT 2.0 as your last configuration step to ensure that all set-
tings are stored safely and are available for the next restart.
11.2

Operation with HSComm Modem

Use the software HSComm to easily configure the INSYS Modem 56k Small INT 2.0.
HSComm offers an interface for the parameters of the most important AT com-
mands of the INSYS Modem 56k Small INT 2.0. The operation is mostly self-
explanatory. You can download the software from the INSYS MICROELECTRONICS
homepage (www.insys-tec.de).
Configuration and settings of the INSYS Modem 56k Small INT 2.0 with HSComm
How to configure the INSYS Modem 56k Small INT 2.0 with the software
HSComm.
The INSYS Modem 56k Small INT 2.0 is connected to the PC and switched
on.
The software HSComm Modem is installed on the PC.
1. Start the program HSComm Modem.
The program starts.
A message window "Read settings..." is displayed.
The program will now search for a connected INSYS Modem 56k Small INT
2.0 and will attempt to read the settings.
After a short time, the settings are read out. A status message "Settings
read." appears.
2. Click OK in the status message.
3. Enter the required settings.
Operating Principle
25
