INSYS Modem 56k Small INT 2.0
12.9

Sending messages via data connection, SMS or Fax

The INSYS Modem 56k Small INT 2.0 can send a message via SMS, data connection, or as
e-mail. The sending of messages can only be triggered via an AT command. By default,
three attempts are made to send a message.
Configuration with HSComm
To define the Type of connection for the message dispatch (mobile, modem,
fax), select the according type in the dropdown menu (Page 28, Figure 6:
HSComm Modem - Tab Alarm functions (pulse input active was selected), po-
sition 11).
A dial character (e.g. "0") for the exchange in phone systems can be entered in
the entry field "Character for exchange" (Page 28, Figure 6: HSComm Modem -
Tab Alarm functions (pulse input active was selected), position 2).
To define a message for the according recipient, enter the message in the en-
try field (Figure 6: HSComm Modem - Tab Alarm functions (pulse input active
was selected), position 6). Enter the phone number of the recipient with the
prefix (or the country prefix) into the field under "Phone number" (Page 28,
Figure 6: HSComm Modem - Tab Alarm functions (pulse input active was se-
lected), position 8). Ensure that the phone number of an SMS service center
from the drop down menu "Service center number" (page 28, Figure 6:
HSComm Modem - Tab Alarm functions (pulse input active was selected), po-
sition 8) is entered.
The number of attempts to send a message can be specified. Three attempts
are set by default. The number of dialing attempts can be increased in the
dropdown field (page 28, Figure 6: HSComm Modem - Tab Alarm functions
(pulse input active was selected), position 3).
It is also possible to send the message independent from the selection con-
nection type to a fax device as well. Activate the check box "FAX group mes-
sage" (page 28, Figure 6: HSComm Modem - Tab Alarm functions (pulse input
active was selected), position 7). Next to the check box, an entry field for the
recipient number is displayed. Enter the number of the fax device, to which
the message is to be sent in addition.
Configuration with AT commands
To enable the SMS dispatch, first define the
phone number of the SMS service center
which is used to send the message.
To prevent that the INSYS Modem 56k Small
INT 2.0 does not wait for a phone number
from the exchange (e.g. for configurations
with phone systems), the dial tone detection
can be turned off.
AT&Z0=Phone number
ATX3
Functions
37
