Operating Principle
4.
Afterwards, click on the button Send (Figure 5: HSComm Modem - Tab Mo-
dem, Position 21).
5.
Click OK in the status message.
A dialog box with the message "Modem settings are sent" is displayed.
The entered settings are sent to the INSYS Modem 56k Small INT 2.0 and
stored.
A dialog box with the message "Modem settings sent" is displayed.
6.
Click OK.
11.3
User Interface of the Software HSComm Modem
In the following, the user interface of the software is displayed. These illustrations
should help you find the different software settings.
Figure 5: HSComm Modem - Tab Modem
26
INSYS Modem 56k Small INT 2.0
