INSYS Modem 56k Small INT 2.0
Command
AT*C
AT&C<n>
AT+CMGF=<n>
AT+CMGS=<n>
Description
Remote configuration password
This password secures the remote configuration as well as incoming data connections
(see AT*P) and security callback.
OLD PASSWORD Requires the old password (default: QWERTY). Wrong input leads
to ERROR.
NEW PASSWORD Enter the new password with 6 to 12 characters.
Repeat the new password. Wrong input leads to ERROR.
CONFIRM
OK The password is immediately stored in the EEPROM.
DCD (CT109) behavior
Behavior of the RS232 DCD output of the INSYS Modem 56k Small INT 2.0.
AT&C0 DCD is always ON
AT&C1 DCD follows the carrier signal of the phone line (default)
Set the SMS dispatch format with AT+CMGS
AT+CMGF=0 Sets the PDU mode for the SMS dispatch via AT+CMGS (default).
AT+CMGF=1 Sets the text mode for the SMS dispatch via AT+CMGS.
SMS dispatch directly via AT command
Depending on the setting of AT+CMFG=<n>, the command AT+CMGS=<n> will have a
different syntax.
Setting AT+CMGF=1 (text mode):
AT+CMGS=<phonenumber>
The INSYS Modem 56k Small INT 2.0 returns the ">" character and awaits the SMS text
(up to 160 characters), ending with an EOF character (0x1A or STRG-Z).
Notes:
Depending on the provider, the phone number must be entered in the format
"0941xxxx" or "49941xxxx" (see AT*M and/or AT&Z2).
After the sending procedure was successful, the INSYS Modem 56k
Small INT 2.0 will return "+CMGS: 000".
Setting AT+CMGF=0 (PDU mode):
AT+CMGS=<PDU string length>
The INSYS Modem 56k Small INT 2.0 returns the character ">" and awaits the PDU
string, ended
with an EOF character (0x1A or STGR-Z).
Notes:
Depending on the provider, the phone number must be entered in the format
"0941xxxx" or "49941xxxx" (see AT*M and/or AT&Z2).
"Numbering Plan" is ignored.
The service center is defined by AT&Z0, the SCA field in the PDU string is ig-
nored.
Message header, confirmation SMS and validity period are not supported.
Data coding scheme: Only the "default alphabet" is supported.
After the sending procedure was successful, the INSYS Modem 56k
Small INT 2.0 will return "+CMGS: <MR>" where <MR> is the message ref-
