INSYS Modem 56k Small INT 2.0
2.
Lift the INSYS Modem 56k Small INT 2.0 perpendicular to the DIN rail until
the plastic spring of the third, flexible snap-in hook engages in the DIN rail.
The INSYS Modem 56k Small INT 2.0 is now completely mounted.
Connecting the power supply
The device has already been mounted to the DIN rail.
The power supply is connected and switched off.
1.
Connect the ground lead of the power supply to the terminal "GND".
2.
Connect the plus pole of the power supply to the terminal for the power
supply.
Mounting
19
