Laser marker (Only the Model C 8FSHE)
Use the laser marker for aligning with the ink line on the
workpiece.
(1) Cutting position can be properly adjusted by aligning the
positioning ink line with the laser line. There is no need to
make a long ink line on the workpiece.
(2) There is no need to lower the motor head to align with the
ink line because the laser marker makes a laser line on the
workpiece. In addition, cutting position can be easily
adjusted because the operator can hold the workpiece with
both hands to move.
(3) Cutting position can be easily adjusted because the laser
line can be aligned with an optionally angled ink line.
(4) Even the workpieces such as crown moldings and base
boards that have decorative surfaces and are difficult to be
made an ink line can be cut just by aligning the laser line
with the ink line on the fence side. The laser line is
adjusted to the width of the saw blade at the time of factory
shipment. Depending upon the user's cutting choice, the
laser line can be aligned with the left side of the cutting
width (saw blade) or the ink line on the right side. Adjust
the position of the laser line according to "Position
adjustment of laser line" on page 17.
LED light (Only the Model C 8FSHE)
The Model C 8FSHE is equipped with an LED light to light up
over a table brightly. The two LEDs incorporated in it light up the
materials and the point of the saw blade brightly. The LED light
can freely move at the time of right and left bevel cutting
because the support is flexible. Therefore, it lights up the
materials and the point of the saw blade brightly at any time.
Lightweight
The Model C 8FSE is most lightweight (14 kg) in the class of 8" (216 mm) slide compound miter saws
because the reinforcement rib of the table is placed in the most suitable position.

SELLING POINT DESCRIPTIONS

Fig. 1-a
Laser
marker
Fig. 1-b
Fig. 1-c
(molding, base board, etc.)
Fig. 2
-1-
Laser beam
