[For the U.S.A and Canada]
Maker
Model name
0° (Right angle)
Left/right 45°
Miter
Right 57°
Left 45°
Bevel
Right 5°
Miter left/right 45°+
bevel left 45°
Miter left/right 45°+
bevel right 5°
Groove cutting width
Miter cutting ranges
Bevel cutting ranges
Compound
(miter + bevel)
cutting ranges
Angle stopper positions
Saw blade external
diameter mm (inch)
(No. of teeth)
HITACHI
C 8FSE/C 8FSHE
65 x 312 (2-9/16" x 12-1/4")
75 x 262 (2-15/16" x 10-5/6")
(with aux. board 30 (1-3/16"))
65 x 220 (2-9/16" x 8-21/32")
75 x 185 (2-15/16" x 7-1/4")
(with aux. board 20 (13/16"))
65 x 170 (2-9/16" x 6-11/16")
75 x 140 (2-15/16" x 5-1/2")
(with aux. board 20 (13/16"))
45 x 312 (1-25/32" x 12-1/4")
50 x 252 (1-15/16" x 9-15/16")
(with aux. board 30 (1-3/16"))
60 x 312 (2-3/8" x 12-1/4")
70 x 252 (2-3/4" x 9-15/16")
(with aux. board 30 (1-3/16"))
45 x 220 (1-25/32" x 8-21/32")
50 x 170 (1-15/16" x 6-11/16")
(with aux. board 30 (1-3/16"))
60 x 220 (2-3/8" x 8-21/32")
70 x 170 (2-3/4" x 6-11/16")
(with aux. board 30 (1-3/16"))
Possible
(with bolt height adjustment)
Left 0° - 45°
Right 0° - 57°
Left 0° - 48°
Right 0° - 5°
Miter left and right
0° - 45°
Bevel left 0° - 45°
Miter left and right
0° - 45°
Bevel right 0° - 5°
0°, Right/left 15°, 22.5°,
31.6° , 45°
216 (8-1/2") (24P)
C 8FB2
65 x 305 (2-9/16" x 12")
75 x 265 (2-15/16" x 10-7/16")
65 x 220
(2-9/16" x 8-21/32")
65 x 175
(2-9/16" x 6-7/8")
45 x 305
(1-25/32" x 12")
-
45 x 220
(1-25/32" x 8-21/32")
-
Possible
(with screw height
adjustment)
Left 0° - 45°
Right 0° - 57°
Left 0° - 45°
Miter left and right
0° - 45°
Bevel left 0° - 45°
0°, Right/left 15°, 22.5°,
31.6°, 35.3°, 45°
216 (8-1/2") (24P)
-10-
(Superior specifications:
P3
70 x 300
(2-3/4" x 11-13/16")
70 x 212
(2-3/4" x 6-11/32")
70 x 160
(2-3/4" x 6-5/16")
50 x 300
(1-15/16" x 11-13/16")
-
50 x 212
(1-15/16" x 6-11/32")
-
Possible
(with screw height
adjustment)
Left 0° - 50°
Right 0° - 60°
Left 0° - 48°
Right 0° - 2°
Miter left and right
0° - 45°
Bevel left 0° - 45°
0°, Right/left 10°,15°, 22.5°,
31.6°, 45°,
Left 50°, Right 60°
216 (8-1/2") (30P)
)
