1. Specifications

Model
0°(Right angle)
Left/right 45°
Miter
Right 57°
Maximum
cutting
dimensions
Left 45°
Height x
Bevel
Width
mm (inch)
Right 5°
Miter left/right 45°+
bevel left 45°
Miter left/right 45°+
bevel right 5°
Miter cutting ranges
Bevel cutting ranges
Compound (miter + bevel)
cutting ranges
Angle stopper positions
Applicable saw blade
Saw blade bore
External diameter of applicable
saw blades
Lower guard lock
Laser marker
Maximum output < 1 mW (CLASS II)
(Only the
Wave length
Model
Laser medium
C 8FSHE)
Power source type and voltage
Type of motor
Full-load current
No-load rotation speed
Max. output
Main unit dimensions
(Width x depth x height)
Weight
Coating
Packaging
Cord
SPECIFICATIONS
65 mm x 312 mm (2-9/16" x 12-1/4"),
75 mm x 262 mm (2-15/16" x 10-5/6") (with aux. board 30 mm (1-3/16"))
65 mm x 220 mm (2-9/16" x 8-21/32"),
75 mm x 185 mm (2-15/16" x 7-1/4") (with aux. board 20 mm (13/16"))
65 mm x 170 mm (2-9/16" x 6-11/16"),
75 mm x 140 mm (2-15/16" x 5-1/2") (with aux. board 20 mm (13/16"))
45 mm x 312 mm (1-25/32" x 12-1/4"),
50 mm x 252 mm (1-15/16" x 9-15/16") (with aux. board 30 mm (1-3/16"))
60 mm x 312 mm (2-3/8" x 12-1/4"),
70 mm x 252 mm (2-3/4" x 9-15/16") (with aux. board 30 mm (1-3/16"))
45 mm x 220 mm (1-25/32" x 8-21/32"),
50 mm x 170 mm (1-15/16" x 6-11/16") (with aux. board 30 mm (1-3/16"))
60 mm x 220 mm (2-3/8" x 8-21/32"),
70 mm x 170 mm (2-3/4" x 6-11/16") (with aux. board 30 mm (1-3/16"))
Left 0° - 45°, Right 0° - 57°
Left 0° - 48°, Right 0° - 5°
Miter left 45° to right 45° + left bevel 0° to 45°
Miter left 45° to right 45° + right bevel 0° to 5°
0°, Right/left 15°, 22.5°, 31.6° and 45°
216 mm (8-1/2") external dia.
U.S.A./Canada
15.9 mm (5/8")
200 mm to 220 mm (7-7/8" to 8-21/32")
U.S.A./Canada
Not provided
400 nm to 700 nm
Laser diode
AC single phase 50/60 Hz, 110 V, 120 V, 220 V to 240 V
AC single phase commutator series motor
110 V: 10 A, 120 V: 9.2 A, 220 V: 5 A, 230 V: 4.8 A, 240 V: 4.6 A
-1
5,500 min
Approx. 2,100 W
555 mm x 790 mm x 485 mm (21-27/32" x 31-3/32" x 19-3/32")
C 8FSE 14 kg (31 lbs.) C 8FSHE 14.5 kg (32 lbs.)
Gunmetallic silver
Corrugated cardboard box
Type: 2-conductor cabtire cable
-6-
C 8FSE/C 8FSHE
Europe/Australia
30 mm (1-11/64")
Europe/Australia
Provided
Length: 1.8 m (6 ft)
Others
25.4 mm (1")
Others
Not provided
