STANDARD ACCESSORIES
ITEM
CODE NO.
NO.
501
940-543
BOX WRENCH 10MM
502
322-955
DUST BAG (BLACK)
OPTIONAL ACCESSORIES
ITEM
ITEM
CODE NO.
CODE NO.
NO.
NO.
601
963-837
NYLON NUT M6
602
329-465
PLATE
603
SUB FENCE
604
949-342
FLAT HD. SCREW M6X25 (10 PCS.)
605
329-464
SUB FENCE ASS'Y
606
321-374
CROWN MOLDING STOPPER (L) ASS'Y
607
960-017
KNOB BOLT M6X32
608
321-390
CROWN MOLDING STOPPER HOLDER
609
CROWN MOLDING STOPPER (L)
610
301-806
WING BOLT M6X15
611
322-957
VISE (B) ASS'Y
612
998-836
KNOB BOLT M6X11
613
SCREW HOLDER (B)
614
306-985
WASHER (H)
615
964-851
BASE RUBBER
616
304-043
MACHINE SCREW (W/WASHERS) M4X10 (BLACK)
617
318-967
VISE SHAFT
618
321-551
KNOB BOLT M10X54
619
329-426
CROWN MOLDING VISE ASS'Y
620
974-561
STOPPER
621
949-404
WING BOLT M6X20 (10 PCS.)
622
321-390
CROWN MOLDING STOPPER HOLDER
623
CROWN MOLDING STOPPER (R)
624
301-806
WING BOLT M6X15
625
321-373
CROWN MOLDING STOPPER (R) ASS'Y
626
HOLDER ASS'Y
627
321-549
HOLDER
628
949-313
WING NUT M6 (10 PCS.)
629
949-556
NUT M6 (10 PCS.)
630
967-329
WASHER (H)
631
996-261
VISE PLATE
632
996-283
HIGH TENSION BOLT M6X65
633
321-553
GUIDE ASS'Y
634
998-840
TCT SAW BLADE 216MM-D15.88 HOLE-NT24
635
998-858
TCT SAW BLADE 216MM-D25.4 HOLE-NT24
636
998-859
TCT SAW BLADE 216MM-D30 HOLE-NT24
- 8 -
DESCRIPTION
DESCRIPTION
*ALTERNATIVE PARTS
NO.
REMARKS
USED
1
1
NO.
NO.
REMARKS
USED
USED
1
1
1
1
1
INCLUD. 601-604
1
INCLUD. 607-610
1
1
1
1
1
INCLUD. 612-618
1
1
1
1
1
1
1
1
INCLUD. 606, 611
1
1
1
1
1
1
INCLUD. 607, 622-624
1
INCLUD. 627-632
2
2
2
4
2
2
1
INCLUD. 607, 620, 621, 626
1
1
1
C 8FSE
Printed in Japan
2 - 08
(080219N)
