WARNING: Always firmly clamp or vise to secure the crown molding to the fence; otherwise the

crown molding might be thrust from the table and cause bodily harm.

Do not perform bevel cutting. The main body or the saw blade may contact the sub

fence, resulting in an injury.

CAUTION: Always confirm that the motor head does not contact the crown molding vise ass'y when

it is lowered for cutting. If there is any danger that it may do so, loosen the 6 mm knob

bolt and move the crown molding vise ass'y to a position where it will not contact the

saw blade.

Position crown molding with its WALL CONTACT EDGE against the guide fence and its CEILING

CONTACT EDGE against the crown molding stoppers as shown in Fig. 32-b. Adjust the crown molding

stoppers according to the size of the crown molding. Tighten the 6 mm wing bolt to secure the crown

molding stoppers. Refer to the following table for the miter angle.

For inside corner

For outside corner

Table 9

Position in Fig. 26

-23-

Miter angle

Right 45°

Save the right side of blade

Save the left side of blade

Left 45°

Save the right side of blade

Right 45°

Save the left side of blade

Finished piece
