• @ CAUTION
‡ @
As an electric wire for the power source, use a 600 V vinyl insulated wire (IEC 227-3) or its equivalent
or above.
‡ A
Attach a round press-fitting terminal with insulated sleeve (for M3.5) to the end of the electric wire.
‡ B
Connect a protective grounding (resistance:100ƒ ¶ or lower, a minimum diameter of a grounding
conductor:1.6mm) to the protective grounding terminal.
‡ C
If other instrument shares the protective grounding conductor, there may be an effect caused by
noise coming from the grounding conductor. It is recommended not to share it with other instrument.
‡ D
In order to comply with the requirements of safety standard EN61010, the recorder shall have one of
the following as a disconnecting device, fitted within easy reach of the operator, and labeled as the
disconnecting device.
• @ ‚ • • D
A switch or circuit breaker which complies with the requirements of IEC60947-1, IEC60947-2
and IEC60947-3.
• @ ‚ ‚ • D
A separable coupler which can be disconnected without the use of a tool.
• @ ‚ ƒ • D
A separable plug, without a locking device, to mate with a socket outlet in the building.
‡ E
This product has designed to conform to IEC1010-1 installation Category‡ U and pollution
degree 2.
4.1.3 Wiring Procedure
CAUTION
The transparent protective cover should surely remove the left and right (both sides) hooks simultaneously.
If it removes by turns, there is a possibility that it may damage.
1) Put your fingers on the left and right (both sides) hooks of the transparent protective cover on the
power source terminal block. Pushing them inside, take out the cover to this side.
2) Connect the power source electric wire refer to Fig. 4.2. Connect the protective grounding to the
terminal. Connect the non-grounding side of the power source to "L" terminal. Connect the
grounding side to the "N" terminal.
3) Put back the transparent protective cover.
4) Make sure that protective grounding is properly provided.
• @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @
• @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @ • @
Fig. 4.2• @ Power source Terminal block
16• \
‚ k
‚ m
HXPRM10mnCT001E
