11.3

Standard Setting Functions

11.3.1
• @ • @ • @ • @ • @ • @ • @ • @ • @ Table 11.5• @ Standard Setting Functions
Function
Burnout
Tag Number
Reference Junction
Compensation
Copy Function
Setting input offset
Zone Recording
(Track Recording)
Partial
compression/expansion
Decade Recording
Indication
Alarm Print
Alarm Recovery Print
Computation
Interchannel
Computation
Alarm Hysteresis Width
11.4

Optional Functions

11.4.1
Chart Feed Start/Stop
Changing Chart Speed
Comment Print (Sync./Async.)
Manual Print (Sync./Async.)
Date and Time Print (Sync./Async.)
11.4.2
6 relays
11.4.3
RS-232C(Standard)
RS-485(option)
Standard Setting Functions
To deflect over toward 100% with disconnecting input. Specifies the every
channel's burnout. (DC voltage of ±50mV max., TC input )
Sets a tag number by 7 figures every channel. (Prints at a logging print)
Specifies an inside/outside of the Reference Junction Compensation.
Copies a channel setting up.
Setting input offset is possible for every channel.
Specifies a recording area every channel to separate into Tracks.
Records Partial Compression/Expansion to 1-crease line every channel.
Records and indicates by 5 decades. It is 2 figures that the effective number
to indicate and print.
Prints Occurrence time, Occurrence channel, Setting No. and Alarm type in
purple at occurring an alarm.
Prints Recovery time, Recovery channel, Setting No. and Alarm type in purple
at recovering an alarm.
Computes Square root.
Computes Sum, Difference and Average computation.
Sets an alarm hysteresis width 0% FS or 0.5% FS.

Remote Function of DI

Function

Alarm Board

Communication unit

Description
Description
Starts with turning to ON. Stops with turning to OFF.
Changes 1st with turning to ON and 2nd with OFF.
Prints Comment with turning to ON.
Prints Manual Print with turning to ON.
Prints Date and Time with turning to ON.
110• \
