5 If your board is wider than 8' (2400mm) or taller than 4' (1200mm),
apply the four self-adhesive border buttons provided to mark the
boundary of CopyCam captures, as shown below. These buttons
remind users what part of the board is captured by CopyCam.
Place four of these on the writing area. Align each corner of the writing
area with this corner on each sheet. Use four pieces of type to ensure
that each sheet lies flat.
Corner Calibration Sheet
6 Remove the calibration sheets and set them aside in a safe place,
such as tucked into this manual.
NOTE: note:
If CopyCam is installed with a blackboard and if white chalk is normally
used, or if printing exclusively to a black and white printer such as a
network laser printer, consider setting CopyCam to capture in
monochrome to optimize capture quality. Refer to "Using the Settings Tab"
for information about capturing in color and monochrome.
32
Center arrow at top of writing area,
under CopyCam arm.
Top Center Calibration Sheet
Calibrating CopyCam
