Preparing to Install the Camera Arm

WARNING
You must fasten the brackets to the wall so they are secure. CopyCam
mounts to any kind of wall construction. Instructions and wall fasteners are
provided to help you install CopyCam when walls have metal or wood
studs. Be sure to locate studs and use them to drive mounting screws if
possible.
Locate and have ready to use:
camera arm positioning template
•
camera arm
•
two #8 x 1.5" (38mm) drywall screws (provided)
•
three toggle bolt screws (provided)
•
two camera arm-securing thumb screws (provided)
•
eight wing nuts (provided)
•
power drill with 1/2" (12mm) bit
•
power screwdriver with phillips bit or phillips screwdriver
•
pencil
•
tape measure
•
ladder
•

Installing the Camera Arm Mounting Plate

These instructions guide you through installing CopyCam on a sheetrock
wall. If your wall material is some other substance, such as concrete or
brick, use these instructions as a guideline but install appropriate anchors
to secure the unit to the wall.
Install the camera arm mounting plate one inch (25mm) above the board.
NOTE: note:
The position of the camera arm is critical to the proper function of the
CopyCam lens and camera. Use the camera arm positioning template
during installation to ensure that the camera will properly focus on the full
board (up to 4' x 8' [1200 mm x 2400 mm]). Refer to "Camera Arm Spatial
Requirements" on page 6.
16 CopyCam Installation
