Page 1: Interactive Whiteboard
Interactive Whiteboard Installation and Operation Guide Part number 370-0257-05 ©2009 PolyVision Corporation All rights reserved... -
Page 2: Table Of Contents
FCC compliance ................14 CE compliance.................. 15 WEEE compliance................15 Appendix 1: Bluetooth pairing options ........... 16 Pairing with the PolyVision Bluetooth adapter ........16 Pairing with Windows or Apple built-in Bluetooth ........ 17 Pairing with third-party Bluetooth ............18 Warranty ....................20... -
Page 3: Overview
Congratulations on your purchase of a PolyVision ēno™ interactive whiteboard. This manual describes how to install and use the ēno interactive whiteboard. For more information about the PolyVision driver that you install on your computer, refer to the PolyVision Driver User Guide which is installed along with the PolyVsion driver. -
Page 4: Register Your Whiteboard
Overview Register your whiteboard By registering your product, you will receive enhanced customer service with information on software upgrades. To register your product: • Register on-line at: www.polyvision.com/support/register.asp Installation and Operation Guide... -
Page 5: Preparing The Ēno Whiteboard For Use
ēno stylus battery is low, to remind you to replace the battery • the stylus has been idle for five minutes, to remind you to replace the Note that NiMH rechargeable batteries are not suitable for the ēno stylus. Lithium batteries give the longest life. PolyVision... -
Page 6: Prepare Your Computer
Prepare your computer To prepare your computer for use: • Install the PolyVision driver as described below in Driver installation. • The ēno stylus is a Bluetooth device and must pair with the computer that interacts with the whiteboard. You can use ēno regardless of whether your computer has Bluetooth capability built-in. -
Page 7: Pairing The Ēno Stylus And Your Computer
Follow the prompts you see on the screen to complete the installation. On a Macintosh, your system automatically reboots. When installation is complete, a message appears on your computer screen and the PolyVision icon appears in your system tray (Windows) or system menu (Macintosh). PolyVision icon The PolyVision driver runs unobtrusively in the background whenever your computer is on. - Page 8 Preparing the ēno whiteboard for use To pair your ēno stylus with your computer any time after the Bluetooth drivers are installed on your computer: On your computer, click the PolyVision icon in your system tray (Windows) or system menu (Macintosh). PolyVision icon Choose “Configure the PolyVision driver”...
-
Page 9: Getting Started With Your Projector
The projected image does not need to fill the white area. To align the projected image with the ēno whiteboard: Assure that at least half of the projected image is actually projected onto the board. Tap the Projection icon on the control strip one time. PolyVision... - Page 10 Preparing the ēno whiteboard for use The alignment window shown below projects from the computer to the whiteboard. Using the ēno stylus, touch exactly on each target projected on the whiteboard, following instructions you see on the board. When alignment is complete, you are ready to begin using your computer and whiteboard in projection mode.
-
Page 11: Using Your Ēno Whiteboard
You can also operate the whiteboard using an on-screen version of the control icons. To use the on-screen control icons: Click the PolyVision driver icon in the system tray (Windows) or system menu (Macintosh). The PolyVision driver menu appears. Choose “Show On-Screen Remote Control” from the menu to toggle on and off the display of on-screen control icons which you tap with the stylus. - Page 12 Using your ēno whiteboard Purpose Control icon Purpose Toggles “projection mode” on / off. The first use starts the onscreen alignment Sets the stylus to narrow (calibration) process. width. Goes to the previous Sets the stylus to PowerPoint slide or PgUp. medium width.
-
Page 13: Led Status Summary
Condition Low Battery Blink every five seconds Hardware Error, Bluetooth Connection Error, Three quick pulses repeated or Bluetooth Pairing Error three times Ready for use Attempting Bluetooth pairing or connection with your computer PolyVision... -
Page 14: Care And Maintenance
Technical support representatives are available Monday through Friday from 8 AM Eastern time to 8 PM Eastern time. • E-mail: support@polyvision.com • Internet: www.polyvision.com Or, outside the USA contact PolyVision Europe/Asia Technical Support: • Phone: +32 (0)89 32 31 30 • E-mail: business.center@polyvision.com •... -
Page 15: Ce Compliance
2006/95/EC Low Voltage Directive EN60950-1:2001 (Safety) 2004/108/EC EMC Directive EN55022:2003 Class B (EMC) EN55024:2003 (EMI) EN301489-17 V1.2.1:2002 EN301489-1 V1.4.1:2002 1995/5/EC R&TTE Directive EN300328-2 V1.6.1:2004 (RF) IEC 60825-1 Class 1 LED WEEE compliance WEEE Directive 2002/96/EC PolyVision... -
Page 16: Appendix 1: Bluetooth Pairing Options
Plug the PolyVision Bluetooth adapter into any available USB port. A message appears when device drivers have been installed. Turn on the ēno stylus by removing the cap. On your computer, click the PolyVision icon appears in your system tray (Windows) or system menu (Macintosh). PolyVision icon Choose “Configure the PolyVision driver”... -
Page 17: Pairing With Windows Or Apple Built-In Bluetooth
Pairing with Windows or Apple built-in Bluetooth If your computer includes the built-in Windows and Macintosh Bluetooth capability and you choose not to use the PolyVision Blluetooth adapter for Bluetooth capability, the PolyVision driver can automatically pair the ēno stylus with your built-in Bluetooth capability. -
Page 18: Pairing With Third-Party Bluetooth
Appendix 1: Bluetooth pairing options Pairing with third-party Bluetooth To use a third-party Bluetooth solution to pair the ēno stylus with your computer: Launch the software that comes with your third-party Bluetooth capability. It may launch from: • The control panel •... - Page 19 PolyVision driver installed on your computer and the ēno stylus: Turn on the ēno stylus by removing the cap. On your computer, click the PolyVision icon appears in your system tray (Windows) or system menu (Macintosh). Choose “Configure the PolyVision driver” from the menu.
-
Page 20: Warranty
During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or similar model) at PolyVision’s option, without charge for either parts or repair labor. Shipping costs will apply. Please keep your original sales receipt or delivery invoice for proof of purchase. - Page 21 If you experience a problem with this product, contact your local dealer or PolyVision Product Support (800.620.POLY in the USA, or +32 (0)89 32 31 30 in Europe) to resolve the problem. If the product is diagnosed as being defective, return the product to the original place of purchase.
- Page 22 HOW STATE LAW RELATES TO THE WARRANTY In the USA, this warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. PolyVision Corporation products are warranted in accordance with the terms of the applicable PolyVision Corporation limited warranty.
-
Page 23: Index
5 NiMH rechargeable batteries, 5 on-screen control icons, 11 overview, 3 pair with different computer, 8 parts replacement, 14 PolyVision Driver User Guide projection mode alignment, 9 exiting, 10 getting set up, 9 register PolyVision, 4 replacement parts, 14...
