Locking the Camera Arm in Place

The camera arm tilts up and locks into position for fastening with two
screws (provided).
To lock the camera arm in place:
1 Determine if there is excess cable, and if there is, push it into the
camera arm cavity through the exit hole at the end of the arm.
2 Tilt up the arm, lifting it slightly so that it slides over the pins on the top
of the mounting plate. It should support its own weight at this point.
Be sure cables are not pinched between the arm and the mounting
plate.
3 Fasten the arm in place using the two arm-securing thumb screws
provided.
22 CopyCam Installation
