To position the camera arm mounting plate:
1 Measure and mark the top center of the horizontal dimension of the
board or imaging area.
2 Locate metal or wooden studs in the wall nearest that location.
3 Punch holes in the camera arm positioning template at the positions of
the four screw holes.
4 Fold the template along the dotted line to form a shelf, as shown.
5 Rest the folded camera arm positioning template on the top edge of
the board, aligning the center line with the center line of your board.
6 Mark the four screw hole positions using an awl, a pencil, or marker.
7 Remove the template. Note if any of the screw positions align with a
stud.
To install the camera arm mounting plate:
NOTE: note:
Three toggle bolts are included for installation of the camera arm. Use the
outside three holes if you must use toggle bolts.
1 At positions that do NOT align with a stud, drill 1/2" (12mm) holes at
the marked positions, using caution not to make the holes too large,
and install a toggle bolt (provided) at each position as follows:
