PolyVision CopyCam Installation And Operation Manual page 14

3 Fold the control pad positioning template along the dotted line to form
a shelf, as shown.
Contr ol
Pad
Moun ting
Temp late
800.620.P OLY
Figu re A
678.542.3 100
+32.089.3 2.31.30
4 Position the folded control pad positioning template on the LEFT
BOTTOM edge of the board, as shown. This indicates the ideal
position and the minimum distance from the board.
5 If possible, locate a metal or wooden stud that is nearest this position.
6 Mark the four screw hole positions on the wall using an awl, a pencil,
or marker so that at least one fastener will attach to the stud, if
possible.
7 Remove the template.
To install the control pad mounting plate:
1 At positions that do NOT align with a stud, drill 1/2" (12mm) holes at
the marked positions, using caution not to make the holes too large,
and install a toggle bolt (provided) at each position as follows:
a Tilt the metal piece so it is flat against the long axis of the two
plastic cords and push it through the 1/2" (12mm) hole, as shown
below.
10
Cop yCam Pro Only
1 1
Fold on
3 3
this line
Mark thes e four
anch ors
hole s for wall
4 4
2 2
if agai nst
Mark cabl e hole Plac e temp late
es in-w all corn er
insta lling cabl the lowe r left
d
of the white boar
or chal kboa rd
(see figur e A)
CopyCam Installation
