a
Tilt the metal piece so it is flat against the long axis of the two
plastic cords and push it through the 1/2" (12mm) hole.
b
Pull back on the toggle bolt to hold the metal piece tight against
the interior of the wall.
c
Slide the plastic cap tight against the exterior of the wall.
d
Snap off the finger hold and plastic cords flush with the wall.
2
Position the camera arm mounting plate over the mounting holes.
3
Drive the toggle bolt screws (provided) through the mounting plate and
toggle bolt, and if a stud was located, drive a #8 x 1.5" (38mm) drywall
screw (provided) through the mounting plate and wall into the stud.
18
CopyCam Installation
