Concealing Cables that are Routed Against the Wall

A cable raceway is provided to conceal cables along one edge of the
board.
To conceal cables:
1 Route cables tightly against the edge of the board.
2 Conceal cables using the cable raceway, elbows, and couplers
provided.
3 If necessary, stow any excess cable in the camera arm cavity by
removing the camera arm cover and pulling cable through the exit
hole.
This completes the installation of CopyCam built-in components. If you are
installing CopyCam Pro, turn to page 26 to install the printer. If you are
installing CopyCam E, turn to "Calibrating CopyCam" on page 28.

Routing Cables Within the Wall

If you are routing CopyCam cables within the walls, the instructions for
mounting the control pad and camera arm differ in the sequence that you
perform steps. Refer to instructions provided in "Mounting the Control Pad
and Camera Arm" on page 8, but proceed in the following sequence:
1 Position the control pad and camera arm positioning templates. Refer
to "To position the control pad mounting plate:" on page 9 and "To
position the camera arm mounting plate:" on page 17.
2 Mark the wall anchor positions and the cable exit hole positions on the
wall.
3 Drill holes. (In some cases, adding conduit within the wall can help to
route the RJ14 cable between the control pad and the camera arm
mounting plate exit holes. Boxes are not recommended.)
4 Drill a hole in the wall for the power cord to exit near an outlet.
5 Install the control pad mounting plate and camera arm mounting plate.
Refer to "To install the control pad mounting plate:" on page 10 and
"To install the camera arm mounting plate:" on page 17.
CopyCam Installation 23
