Field wiring and signal termination

You can use the following MCC screw terminal boards to terminate field signals and
route them into the PCI-DAS6013 or PCI-DAS6014 board using the C100FF-x cable:
ISO-RACK16/P – 16-channel isolation module mounting rack. Details on this
product are available on our web site at
http://www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=127&pf_id=1111.
ISO-DA02/P (PCI-DA6014 only) – Two-channel, 5B module rack. Details on this
product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=128&pf_id=710.
BNC-16SE – 16-channel single-ended BNC connector box. Details on this product
are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=713.
BNC-16DI – Eight-channel differential BNC connector box. Details on this product
are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=714.
CIO-MINI50 – 50-pin universal screw terminal accessory. Details on this product
are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=258.
CIO-TERM100 – 16x4 screw terminal. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=281.
100
51
Figure 2-2. C100MMS-x Cable
Field wiring connections:
