Chapter 6 Specifications; Analog Input Section - Measurement Computing PCI-DAS6013 User Manual

Specifications
Typical for 25°C unless otherwise specified.

Analog Input Section

A/D converter
Resolution
Number of channels
Input ranges
A/D pacing
Burst mode
A/D Gate Sources
A/D gating modes
A/D trigger sources
A/D triggering modes
ADC Pacer Out
RAM buffer size
Data transfer
DMA Modes
Configuration Memory
Streaming-to-disk rate
Successive Approximation type, min 200kS/s conversion
rate.
16 bits, 1-in-65536
16 single ended /8 differential, Software selectable
±10V, ±5V, ±500mV, ±50mV, Software selectable
Internal counter – ASIC. Software selectable time base:
Internal 40MHz, 50ppm stability
External Source via AUXIN<5:0>, Software selectable.
External convert strobe: A/D CONVERT
Software paced
Software selectable option, burst rate = 5µs.
External digital: A/D GATE
External digital:
Programmable, active high or active low, level or edge
External digital: A/D START TRIGGER
External digital: Software-configurable for rising or falling
edge.
Pre-/Post-trigger: Unlimited number of pre-trigger samples,
16 Meg post-trigger samples.
Available at user connector: A/D PACER OUT
8K samples
DMA
Programmed I/O
Demand or Non-Demand using scatter gather.
Up to 8K elements. Programmable channel, gain, and offset
200kS/s, system dependent
6-1
Chapter 6
A/D STOP TRIGGER
