PCI-DAS-TC User's Guide
1
20
37
19

Field wiring, signal termination and conditioning

You can use the following screw terminal adapter board (with CJC sensor and isothermal block) to terminate
field signals and route them into the PCI-DAS-TC using the C37FFS-x cable.
! CIO-STA-TC – Isothermal block with CJC sensor. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=116&pf_id=1209.
Figure 2-2. C37FFS-x cable
2
-4
Installing the PCI-DAS-TC
1
20
37
19
