PCI-DAS6013 and PCI-DAS6014 User's Guide
SCB-50 – 50 conductor, shielded signal connection/screw terminal box provides
two independent 50-pin connections. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1168.
You can use the following MCC screw terminal boards to terminate field signals and
route them into the PCI-DAS6013 or PCI-DAS6014 board using the C100MMS-x cable:
SCB-100 – 50 conductor, shielded signal connection/screw terminal box provides
two independent 50-pin connections. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1168.
2-11
Installing the Board
