PCI-DAS6013 and PCI-DAS6014 User's Guide

Connecting the board for I/O operations

Connectors, cables – main I/O connector
Table 2-1 lists the board connectors, applicable cables, and compatible accessory
products for the PCI-DAS6013 and PCI-DAS6014.
Table 2-1. Board Connectors, Cables, and Accessory Equipment
Connector type
Compatible Cables
Compatible accessory products
(with the C100HD50-x cable)
Compatible accessory products
(with the C100MMS-x cable)
Shielded, SCSI 100-pin D-type
C100HD50-x unshielded ribbon cable. x = 3 or 6 feet.
(see Figure 2-1 on page 2-9)
C100MMS-x cable shielded round cable. x= 1, 2, or 3
meters (see Figure 2-2 on page 2-10)
ISO-RACK16/P
ISO-DA02/P (PCI-DA6014 only)
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
SCB-100
2-6
Installing the Board
