Field wiring, signal termination and conditioning

You can use the following BNC and screw terminal boards to terminate field signals and
route them into the PCI-DAS6052 using the C100HD50-x cable:
BNC-16SE – Brings analog signals to standard BNC connectors. Designed for
boards operating in single-ended mode. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=713.
BNC-16DI – Brings analog signals to standard BNC connectors. Designed for
boards operating in differential mode. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=714.
CIO-MINI50 – 50-pin screw terminal board. Two boards are required. Details on
this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=258.
CIO-TERM100 – 100-pin screw terminal board (daisy-chained 50-pin IDC
connectors). Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=281.
SCB-50 – 50 conductor, shielded signal connection/screw terminal box provides
two independent 50-pin connections. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1168.
You can use the following screw terminal box to terminate field signals and route them
into the PCI-DAS6052 board using the C100MMS-x cable:
SCB-100 – 100 conductor, shielded signal connection/screw terminal box provides
two independent 50-pin connections. Details on this product are available on our
web site at
Analog signal conditioning and expansion
You can use the following signal conditioning accessory products with the C100HD50-x
cable:
ISO-RACK-16/P – 16-channel ISO-5B module rack for connecting an ISO-5B
module to an analog input. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=127&pf_id=1111.
ISO-RACK-DA02/P – 2-channel, 5B module rack for 50-pin DA02 & 100-pin
series, detachable terminals are available. Details are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=128&pf_id=711.
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1169
