Counter Section
User counter type
Number of Channels
Resolution
Compatibility
CTRn base clock source
(Software selectable)
Internal 10MHz clock source
stability
Counter n Gate
Counter n Output
Clock input frequency
High pulse width (clock input)
Low pulse width (clock input)
Gate width high
Gate width low
Input low voltage
Input high voltage
Output low voltage
Output high voltage
82C54
2
16-bits
5V/TTL
Internal 10MHz, Internal 100KHz or External connector
(CTRn CLK)
50ppm
Available at connector (CTRn GATE).
Available at connector (CTRn OUT).
10 MHz max
15ns min
25ns min
25ns min
25ns min
0.8V max
2.0V min
0.4V max
3.0V min
6-8
