PCI-DAS6013 and PCI-DAS6014 User's Guide
Analog Input / Output Calibration
Recommended warm-up time
Calibration
Onboard calibration reference
Calibration interval
Digital Input / Output
Digital Type:
Number of I/O
Configuration
Input high voltage
Input low voltage
Output high voltage (IOH = -
32mA)
Output low voltage (IOL =
32mA)
Data Transfer
Power-up / reset state
15 minutes
Auto-calibration, calibration factors for each range stored on
board in non-volatile RAM.
DC Level: 10.000V± 5mv. Actual measured values stored in
EEPROM.
Tempco: 5ppm/°C max, 2ppm/°C typical
Long-term stability: 15ppm, T = 1000 hrs, non-cumulative
1 year
Discrete, 5V/TTL compatible
8
8 bits, independently programmable for input or output. All
pins pulled up to +5V via 47K resistors (default). Positions
available for pull down to ground. Hardware selectable via
solder gap.
2.0V min, 7.0V absolute max
0.8V max, –0.5V absolute min
3.80V min, 4.20V typ
0.55V max, 0.22V typ
Programmed I/O
Input mode (high impedance)
6-6
Specifications
