CIO-DIO24H User's Guide

Cabling

37
20
37
20

Field wiring, signal termination, and conditioning

You can use the following cabling, screw termination, and signal condi
– 37-pin screw terminal board. Details on this product are available on our web site at
CIO-MINI37
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=1543.
– 16" X 4" termination panel which mates with both 37-pin and 50-pin connectors. Details
CIO-SPADE50
on this product are available on our web site at
– 8-channel, solid-state relay mounting rack for digital signal conditioning. Details on this
SSR-RACK08
product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=620.
– 24-channel, solid-state r elay mounting rack for digital signal conditioning. Details on this
SSR-RACK24
product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=1193.
– 24 Form C relays, 6 Amp relay accessory board for digital signal conditioning. Details on
CIO-ERB08
this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=240.
– 24 Form C relays, 6 Amp relay accessory board for digital signal conditioning. Details on
CIO-ERB24
this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=241.
In formation on signal connections
General information regarding signal connection and configuration is available in the Guide to Signal
Connections. This document is available on our web site at www.mccdaq.com/signals/signals.pdf.
19
The red stripe
identifies pin # 1
1
Figure 6. C37FF-x cable
19
1
Figure 7. C37FFS-x cable
37
20
tioning products with the CIO-DIO24H.
www.mccdaq.com/pdfs/scr
14
Installing the CIO-DIO24H
19
1
19
37
20
1
ew.pdf .
