PCI-DAS6013 and PCI-DAS6014 User's Guide

8 Channel Differential Mode

Pin Signal Name
1 LLGND
2 CH0 IN HI
3 CH0 IN LO
4 CH1 IN HI
5 CH1 IN LO
6 CH2 IN HI
7 CH2 IN LO
8 CH3 IN HI
9 CH3 IN LO
10 CH4 IN HI
11 CH4 IN LO
12 CH5 IN HI
13 CH5 IN LO
14 CH6 IN HI
15 CH6 IN LO
16 CH7 IN HI
17 CH7 IN LO
18 LLGND
19 n/c
20 n/c
21 n/c
22 n/c
23 n/c
24 n/c
25 n/c
26 n/c
27 n/c
28 n/c
29 n/c
30 n/c
31 n/c
32 n/c
33 n/c
34 n/c
35 AISENSE
36 D/A OUT 0*
37 D/A GND*
38 D/A OUT1*
39 PC +5 V
40 AUXOUT0 / D/A PACER OUT
41 AUXOUT1 / A/D PACER OUT
42 AUXOUT2 / SCANCLK
43 AUXIN0 / A/D CONVERT
44 n/c
45 AUXIN1 / A/D START TRIGGER
46 AUXIN2 / A/D STOP TRIGGER
47 AUXIN3 / D/A UPDATE
48 AUXIN4 / D/A START TRIGGER
49 AUXIN5 / A/D PACER GATE
50 GND
* = n/c on PCI-DAS6013
Pin Signal Name
51 n/c
52 n/c
53 n/c
54 n/c
55 n/c
56 n/c
57 n/c
58 n/c
59 n/c
60 n/c
61 n/c
62 n/c
63 n/c
64 n/c
65 n/c
66 n/c
67 n/c
68 n/c
69 n/c
70 n/c
71 n/c
72 n/c
73 n/c
74 n/c
75 n/c
76 n/c
77 n/c
78 n/c
79 n/c
80 n/c
81 n/c
82 n/c
83 n/c
84 n/c
85 DIO0
86 DIO1
87 DIO2
88 DIO3
89 DIO4
90 DIO5
91 DIO6
92 DIO7
93 CTR1 CLK
94 CTR1 GATE
95 CTR1 OUT
96 GND
97 CTR2 CLK
98 CTR2 GATE
99 CTR2 OUT
100 GND
6-11
Specifications
