PCI-CTR05 User's Guide
1
20
37
19

Field wiring, signal termination and conditioning

You can use the following MCC screw terminal boards with the PCI-CTR05 board using the C37FF-x or
C37FFS-x cable.
SCB37 — 37-conductor, shielded signal connection/screw terminal box that provides two
independent 37-pin connections. Details on this product are available at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1166.
CIO-MINI37 — 4 x 4, 37-pin screw terminal board. Details on this product are available at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=255.
CIO-MINI37-VERT — 37-pin screw terminal accessory with vertical 37-pin male D connector.
Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=256.
CIO-TERMINAL — 16 X 4 universal screw terminal board with on-board prototype area and
circuitry. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=282.
Figure 2-3. C37FFS-x cable
2-5
