PCI-DAS6013 and PCI-DAS6014 User's Guide

Noise Performance

Table 6-4 below summarizes the noise performance for the PCI-DAS6014/6013. Noise
distribution is determined by gathering 50K samples with inputs tied to ground at the
user connector. Samples are gathered at the maximum specified single-channel-
sampling rate. Specification applies to both single-ended and differential modes of
operation.
Range
±10V
±5V
±500mV
±50mV

Analog Output Section (PCI-DAS6014 only)

D/A Converter type
Resolution
Number of Channels
Voltage Range
Monotonicity
DNL
Slew Rate
Settling Time (full scale step)
Noise
Glitch Energy
Current Drive
Output short-circuit duration
Output coupling
Output impedance
Power up and reset
Range
±10V
Table 6-4 – Analog Input Noise Performance
Typical Counts
7
7
11
45
Double-buffered, multiplying
16 bits, 1-in-65536
2 voltage output
±10V
16-bits, guaranteed monotonic
±2 LSB typ
15V/µs min
8 µs to ±1.0 LSB accuracy
360uVrms, DC to 400kHz BW
200mV @ 1µs duration, mid-scale
±5 mA
Indefinite @25mA
DC
0.1 ohms max
DACs cleared to 0 volts ±250mV max
Table 6-5 – Analog Output Absolute Accuracy
6-4
LSBrms
0.9
0.9
1.1
6.7
Absolute Accuracy
±12.6 LSB
Specifications
